SolaHD HS1F500B Non-Ventilated Automation Transformer, 1 Phase, Encapsulated, 0.5 kVA, 240/480V - 120/240V, 2.08/1.04 Amp, 60 Hz, 10" Height, 6" Width, 5" Length,

Brand: Sola

Features:

• Chopper lead wire terminations. Conduit knockouts for side entry into wiring compartment
• Ul listed/nema type 3R enclosure for indoor and outdoor service
• Single phase, non encapsulated, .05 - .250 kva.: low temperature rise, ul class 130°c insulation system, 80°c temperature rise under full load
• Country of origin: United States

Release Date: 12-04-2017

model number: HS1F500B

Part Number: HS1F500B

Details: Automation Transformers are non-ventilated, 50 VA to 45 kVA encapsulated transformers rated for use in hazardous locations as well as harsh industrial environments. Encapsulation and rugged NEMA 3R enclosures protect the transformer from dust and moisture while providing extra shock and vibration resistance. UL Listed transformers fully comply with the latest edition of the National Electrical Code for Class I, Division 2, Group A-D locations when installed in compliance with NEC 501.100(B).

EAN: 0783472100583

Package Dimensions: 13.8 x 10.0 x 7.8 inches
